Plant Transpiration Rate Meter PTRM-3080C
Brand BIOBASE
Product origin CHINA
Delivery time Within 7 days
Supply capacity Factory Direct Supply
Model PTRM-3080C
Introduction：
It is a scientific research plant porometer with open circuit measurement. It is used to measure the influence of various factors on the stomatal behavior of leaves. It can easily, repeatedly and accurately calculate stomatal impedance, stomatal conductance and transpiration rate. It is widely used in the research of water physiology of plant leaves, crop water utilization, water stress damage, and biochemical control and regulation effects.
Download
Features:
1. Data transmission: USB connection to the computer can be directly exported data.
2. Data storage: memory 16G, can be expanded to 32G.
3. Display: 3.5"TFT true color LCD color monitor, clearly visible under bright light.
4. Buttons: Easy to operate, can be set to modify the date, time, measurement interval, data collection times and test name.
TechnicalParameters:
Model | PTRM-3080C | |
Air Temperature | Range | -20~80℃ |
Resolution | 0.1℃ | |
Error | ±0.2℃ | |
Leaf Temperature | Range | -20~60℃ |
Resolution | 0.1℃ | |
Error | ±0.2℃ | |
Air Humidity | Range | 0~100% |
Resolution | 0.1% | |
Error | ≤1% | |
PARin(Optional) | Range | 0~2500μmolm/m2·s |
Accuracy | ±5μmolm/m2·s | |
Response Wavelength Range | 400～700nm | |
PARout | Range | 0~2500μmolm/m2·s |
Accuracy | ±5μmolm/m2·s | |
Response Wavelength Range | 400～700nm | |
Leaf Chamber Size | Type Ⅰ: 30*10mm Type Ⅱ: 30*20mm (Standard) Type Ⅲ: 30*30mm | |
Power Supply | DC8.4V rechargeable lithium battery | |
Packing Size(W*D*H) | 550*400*300cm | |
Gross Weight | 10kg | |
