Table Top High Speed Refrigerated Centrifuge BKC-TH18R
Brand BIOBASE
Product origin CHINA
Delivery time Within 7 days
Supply capacity Factory Direct Supply
Model BKC-TH18R
Introduction:
The BIOBASE Table Top High Speed Refrigerated Centrifuge combines powerful separation performance with precise temperature control, making it an ideal choice for high-demand laboratory applications. Compact yet highly efficient, it is designed to deliver rapid results while protecting sensitive samples from heat damage.
Download
Features:
1. Microcomputer control, large screen color LCD, full touch screen operation interface.
2. Brushless AC variable frequency motor drive.
3. Double door cover lock system, ensure running safety.
4. Provide 20 kinds of working program storage, easy to use and improve work efficiency.
5. Provide 15 kinds of acceleration/deceleration.
6. It has two timing functions: setting and jog.
7. Differential centrifugation: five differential centrifugation procedures are reserved.
8. Double layer steel structure, spray anti-corrosion coating surface of centrifugal chamber.
9. Automatic balance and unbalance protection.
10. Soft braking function, it can effectively prevent sample resuspension and protect sensitive samples.
11. Countdown function: the countdown in seconds, real-time display of remaining working time.
12. The centrifuge can customize 485 communication interface function and operate through remote control.
13. Condensate drainage holes are provided in the centrifugal chamber.
14. Pre-cooling function: In standby mode, the centrifuge can continuously cool to the set temperature.
15. Automatic standby function: When the temperature drops to the set temperature, the compressor automatically stands by.
16. Quick cooling function: When the temperature drops from 21°C to 4°C, the biological zero point, the cooling time is less than 5 minutes.
17. The rotor can withstand high temperature and pressure sterilization at 121°C for more than 2 hours, airtight angle rotor, high biological safety.
18. Automatic magnetic rotor recognition.
19. Famous brand compressor, fluorine-free refrigeration technology.
Technical Parameters:
Model | BKC-TH18R |
Max. Speed | 18800rpm |
Max. RCF | 26870×g |
Max. Capacity | 10ml*12 |
Speed Precision | ±10rpm |
Temp. Range | -20°C~40°C |
Temp. Accuracy | ±1°C |
Timing Range | 1s~99h59min59s/jog |
Noise | ≤58dB |
Power Supply | AC220V, 50/60Hz(Standard); AC110V, 50/60Hz(Optional): External transformer |
External Size(W*D*H)mm | 613*382*325 |
Package Size(W*D*H)mm | 740*550*490 |
Net Weight(kg) | 57 |
Gross Weight(kg) | 71.3 |
Rotor:
Rotor No. | Max. Capacity | Max. Speed(rpm) | Max. RCF(×g) |
H0.512 | 12*0.5ml | 18800 | 18967 |
H0.524 | 24*0.5ml | 18800 | 26870 |
H0212 | 12*1.5/2.2ml | 18800 | 26870 |
H0224 | 24*1.5/2.2ml | 15800 | 24365 |
H0512 | 12*5ml | 16000 | 19462 |
H0612 | 12*5ml cryotubes | 13000 | 16155 |
H0712 | 12*5ml vacuum blood tube | 8000 | 7119 |
H1012 | 12*10ml | 13500 | 17645 |
H0.548 | 48*0.5ml | 13000 | 14737 |
H0.232 | 4*8*0.2ml-strip PCR tube | 13500 | 14059 |
H0.264 | 8*8*0.2ml-strip PCR tube | 13000 | 14926 |
H0.136 | Capillary rotor 36pcs 1.75*75mm | 12000 | 16904 |
Note: The default is round-bottom tube, with mark (▲) is sharp-bottom tube.
