Surgical Shadowless Lamp BK-LED500 BK-LED700 BK-LED500/700
Brand BIOBASE
Product origin CHINA
Delivery time Within 7 days
Supply capacity Factory Direct Supply
Model BK-LED500 BK-LED700 BK-LED500/700
Introduction:
The Surgical Shadowless Lamp is a precision-engineered lighting solution designed to deliver bright, shadow-free illumination in operating rooms.
Download
Features:
1. Cold Light Source Technology
Advanced LED cold light source with zero UV/IR emission. Temperature rise ≤1°C in surgical areas, 80,000+ hours lifespan, energy-efficient and eco-friendly.
2. Intelligent Optical Adjustment
Multi-level adjustable color temperature (3000K-6700K). High CRI (Color Rendering Index) enhances tissue contrast visualization. Uniform light column ensures deep-cavity illumination while reducing visual fatigue.
3. Precision Control System
LCD touch interface with one-touch endoscopic mode. Preset memory for customized parameters. Multi-channel independent control ensures uninterrupted illumination during single-LED failure.
4. Sterile & Purification-Optimized Design
Seamless aerodynamic housing with aluminum alloy heat dissipation. Silicone-sealed dustproof construction complies with laminar airflow standards. Easy-to-clean surfaces support aseptic protocols.
5. Articulated Suspension System
Dual curved arms + multi-joint linkage. 340° horizontal rotation, 90° vertical range, and precision positioning. 50,000-cycle endurance tested for multi-angle adaptability in complex procedures.
6. Autoclavable Focus Handle
Stepless focus adjustment with detachable high-temperature-resistant handle (≤160°C autoclave compatible), enabling rapid intraoperative sterilization.
7. Premium Components
MEAN WELL power supplies (Taiwan-based). Swiss-made antibacterial and flame-retardant coating (EU ROHS-certified) ensures safety and durability.
8. Base
Rigorously validated via mechanical simulation, the "M"-shaped base integrates four-wheel support, weighted steel plates, and silent wear-resistant casters—ensuring stability, easy maneuverability, and secure positioning anywhere.
Technical Parameters:
Model | BK-LED500L | BK-LED700L |
Number of LEDs | 48 | 80 |
Center Illuminance(LUX at 1M) | 40000~160000 (Adjustable) | |
Color Temperature(K) | 3000K ≤ Tc ≤ 6700K (Adjustable) | |
Color Rendering Index(Ra) | 85 ≤ Ra ≤ 100 | |
Spot Diameter(mm) | ≥120 | |
Spot Distribution Diameter(mm) | ≥60 | |
Light Column Depth(mm) | ≥800 | |
Irradiance(W/m²) | ≤900 | |
Temp. Rise at Surgeon's Head(°C) | ≤1 | |
Temp. Rise in Surgical Field(°C) | ≤2 | |
Average Lamp Life(h) | ≥80000 | |
Lamp Power | 1W | |
Power Supply | AC100~240V,50/60Hz | |
Consumption | 200VA | |
Packing Size(W*D*H) | 765*590*215mm; 1060*220*200mm; 840*860*300mm | 765*590*215mm; 1060*220*200mm; 1035*965*305mm |
Net Weight | 74kg | 77kg |
Gross Weight | 48kg;19kg;14kg | 48kg;19kg;19kg |
