Medical Trinocular Biological Microscope BM-8CA
Brand BIOBASE
Product origin CHINA
Delivery time Within 7 days
Supply capacity Factory Direct Supply
This microscope system is a professional grade trinocular biological inverted microscope with super widefield eyepieces, and long working distance PLAN objectives. It is designed for the applications involving biological specimens in large vessels. This microscope will allow you to observe specimen in culture flasks, Petri dishes or other similarly sized containers, and it comes with long working distance PLAN objectives, high quality phase contrast objectives, super widefield eyepieces, 45 degree inclined trinocular head.
Download
Technical Parameters:
Model | BM-8CA |
View Head | Compensation free trinocular head, Inclined at 30°, 360° rotatable, Interpupillary 55~75mm |
Eyepiece | P10X/18mm, P16X/11mm |
Objective | 4X N.A=0.10 WD=37.50mm |
10X N.A=0.25 WD=7.31mm | |
40X N.A=0.65 WD=0.63mm | |
100X(Oil) N.A=1.25 WD=0.18mm | |
Focusing | Coaxial Coarse ＆ Fine Adjustable System, Range 30mm, Fine Division 0.002mm |
Stage | Mechanical Stage 140*140mm, Moving Range 75*50mm, Vernier 0.1mm |
Condenser | Abbe NA1.25 centerable condenser with Iris Diaphragm ＆ Filter |
Illumination | Halogen lamp 6V/20W, Kohler illumination, brightness adjustable |
Filter | Blue, yellow, green |
Power Supply | AC85~265V， 50/60Hz |
Package Size | 425*330*280mm |
Gross Weight | 7.5kg |
