EC Series Class II B2 Biological Safety Cabinet
Brand BIOBASE
Product origin CHINA
Delivery time Within 7 days
Supply capacity Factory Direct Supply
Model EB2-3F EB2-4F EB2-5F EB2-6F
Introduction:
Biosafety cabinet is a box-type air purification negative pressure safety device that can prevent the aerosol escape of some dangerous or unknown biological particles in the process of experimental operation. It is widely used in scientific research, teaching, clinical testing and production in the fields of microbiology, genetic engineering and biological products, and is the most basic safety protection equipment in the first-level protective barrier of laboratory biosafety.
Download
Features:
1. 7-inch large touch color display: touch operation, real-time and clearer display of various values of the safety cabinet, dynamic air flow pattern diagram, fault alarm sound and light prompt.
2. The power-on password can be set to prevent mis-operation by irrelevant personnel.
3. Automatically adjust the wind speed.
4. Power-failure memory, restore the state before power-failure, and have a visual reminder to alarm.
5. Interlocking function: UV lamp and front window; UV lamp and fan; fan and front window.
6. It has an appointment timing function, which can automatically set the timing of turning on, turning off and the running time of the UV lamp, fan, and socket.
7. The rear of the operating area is equipped with anti-paper dust structure to prevent paper scraps from entering the air duct cavity.
Technical Parameters：
Model | EB2-3F | EB2-4F | EB2-5F | EB2-6F | |
External Size(W*D*H) | 1100*800*2250mm | 1300*800*2250mm | 1500*800*2250mm | 1800*800*2250mm | |
Internal Size(W*D*H) | 940*600*660mm | 1150*600*660mm | 1350*600*660mm | 1625*600*660mm | |
Tested Opening | Safety height 200mm(8") | ||||
Max Opening | 460mm | ||||
Inflow Velocity | 0.53±0.025m/s | ||||
Downflow Velocity | 0.33±0.025m/s | ||||
ULPA Filter | Two, 99.9995% efficiency at 0.12μm, filter life indicator | ||||
Front Window | Manual and electric. Tempered glass≥5mm. Anti UV | ||||
Noise | ≤65dB | ||||
UV Lamp | 30W*1 | 30W*1 | 40W*1 | 40W*1 | |
UV timer, UV life indicator, emission of 235.7 nanometers for most efficient decontamination | |||||
LED Lamp | 12W*2 | 14W*2 | 16W*2 | 16W*2 | |
Illumination | ≥1000Lux | ||||
Consumption | 800W | 850W | 1300W | 1300W | |
Waterproof Socket | Two, total load of two sockets: 500W | ||||
Display | LCD display: exhaust filter and downflow filter pressure, filter and UV lamp working time, inflow and down flow velocity, filter life, humidity and temperature, system working time etc | ||||
Control System | Microprocessor | ||||
Airflow System | 0% air recirculation, 100% air exhaust | ||||
Visual And Audio Alarm | Filter replacement, window over height, abnormal air flow velocity, high filter pressure, abnormal power failure | ||||
Material | Work Zone: 304 stainless steel | ||||
Main Body: Cold-rolled steel with anti-bacteria powder coating | |||||
Work Surface Height | 770mm(Can be customized) | 800mm(Can be customized) | |||
Caster | Footmaster caster | ||||
Power Supply | AC220V, 50/60Hz; 110V, 60Hz | ||||
Standard Accessory | LED lamp 2pcs, UV lamp 2pcs, Base stand, Foot switch, Drain valve, Waterproof sockets 2pcs, EC fan, Exhaust blower, Exhaust duct, Remote control | ||||
Optional Accessory | Water and gas tap, Electric height adjustable base stand, Armrest | ||||
Gross Weight | 296kg; 58kg | 329kg; 63kg | 366kg; 63kg | 431kg; 72kg | |
Package | Main Body Exhaust Blower(W*D*H) | 1230*1060*1840mm | 1430*1060*1840mm | 1630*1060*1840mm | 1930*1060*1840mm |
930*800*700mm | 930*860*740mm | 930*860*740mm | 930*860*740mm | ||
